Product Description
Product Description
Hebei Zhuote fence panels panels comply with ASTM A392-06 standards, having superior exposure and corrosion resistance, and perfect for the demands of an outdoor construction site. Some of the most common uses for chain link fence panels include high-rise commercial construction sites, home developments, highway projects, and store front renovations.
Chain link temporary fencing specification:
| Construction Chain Link Fence Panels Height*Width | |||
| 4'/1220mm6'/1830mm8'/2430mm | 9.5'/2900mm12'/3650mm10'/3048mm14'/4300mm | ||
| CUSTOMIZED AVAILABLE | |||
| Temporary Chain link Fence Tube optional | |||
| · 1¼" /1.250inch/32.00mm | · 16.5ga/1.50m | ||
| · 1⅜"/ 1.400inch/35.00mm | · 16ga /1.60mm | ||
| · 1"⅗/ 1.600inch/40.00mm | · 15ga/1.80mm | ||
| · 1⅝" / 1.625inch/41.20mm | · 14ga/2.00mm | ||
| · Cusotmized available | · Cusotmized available | ||
| Outer pipes | · Gauge of Pipe | ||
| Temporary Fence Chain Link Infill Mesh Aperture and Wire Gauge | |||
| ·2"x2"/(50mm x 50mm)2¼"x2¼"(57mmx57mm)2⅜"x2⅜"(60mmx60mm)2½"x2½"(63mmx63mm) | 10ga/3.2mm ,10.5ga/3.00mm ,11ga/2.90mm,11.5ga/2.75mm,12ga /2.60mm12.5ga/2.5mm13ga/2.3m | ||
| Chain Link Mesh Aperture | Wire Gauge | ||
| Customized Available | |||
| Hot dipped Galvanized To be1.2 oz/ft2 [366g/m2]1.8 oz/ft2 [500g/m2]2.0 oz/ft2 [610g/m2] | |||
| Temporary Chain Link Fence /Construction Fence Panels Spec | |
| Tubing | 1¼"(32mm) 1⅜"(35mm) 1½"(38mm) 1⅗"(40mm) 1⅝"(42mm) 1⅞"(48mm)and so on |
| Thickness of Tubing | 16GA/ 1.6mm thick as a standard or customized owned size |
| Chain mesh aperture | 2"x2/"(50mm x 50mm) 2¼"x2¼"(57mmx57mm) 2⅜x2⅜(60mmx60mm) 2½"x2½" (63mmx63mm) |
| Height | 4ft/1220mm 6ft/1820mm 8ft/2420mm |
| Width | 12ft /3650mm was wide acceptance by market also 8ft 9ft 10ft 14ft |
| Panels Size | 6ft x 12ft ,8ft x 12ft, 4ft x 12ft and so on |
| Diameter /Gauge | 10ga/3.2mm ,10.5ga/3.00mm ,11ga/2.90mm,11.5ga/2.75mm,12ga /2.60mm 12.5ga/2.5mm 13ga/2.3m |
| Base Optional 1 | 36" length x 30" width x 8" Height /914mmx762mmx203mm |
| Base Optional 2 | 36" length x 16" width x 8" Height /914mmx406mmx203mm |
| Base Optional 3 | 30" length x 18" width x 8" Height /762mm x460mm x203mm |
| Standard | ASTM A392-06 |
| Steel | Galvanized Steel Construction |
| Finish | Corrosion-Resistant Zinc Coating |
| Transport Packing | Metal pallet Wrapped with Plastic |
| HDG zinc thickness | 14 microns 100gram/SQM 28 microns 200 gram/SQM 42 microns 300 gram/SQM and 84 microns 600 gram/SQM |
Chain Link Benefits:
1. Quick and easy to install.
2. Easy to relocate.
3. Protects your valuable assets and protects you against Public Liability claims.
4. Panel size means that only one panel needs removing for vehicular and machinery access.
